OVJA 1.6 EE 3/2 WT

A real winner in double jersey jacquard structures in dial and cylinder

The OVJA 1.6 EE 3/2 WT is a double jersey jacquard machine with 3-way electronic needle selection in the cylinder and 2-way in the dial. That makes sure it is all in the OVJA 1.6 EE 3/2 WT: Multi-colour jacquard, tuck structures, spacer fabric, and double-knit fabric with a lay-in thread. The OVJA 1.6 EE 3/2 WT features individual needle selection in the cylinder and dial. Both areas are temperature-controlled and can be heated or cooled as required. That makes sure the knitting machine is at operating temperature when you need it to be. And its output is always of equal quality, no matter what the climate – or the yarn that is used. When equipped with special needles, the OVJA 1.6 EE 3/2 WT processes yarn up to 1,200 denier. That means gauges as coarse as E16 are within easy reach.

In combination with Mayer‘s design software MDS 1, the machine has another highlight in store: cylinder-side floats on the reverse of the fabric are integrated automatically.

You are looking for sturdy materials that withstand heavy-duty just as much as harsh weather? Fabrics that can protect you against injuries? Then the OVJA 1.6 EE 3/2 WT knits what you demand. Its fabrics meet any requirements you may have on mattress covers, upholstery, seat covers in trains and cars. The protective features of its fabrics can be put to fashionable use in shoe uppers as well as in outerwear and sportswear, e.g.
for fencing or ice hockey.

Technical features:

Type
Double Jersey

Structures
Double cloth / mattress
Distance knitting
Electronic jacquard

Application
Sports & leisure
Outerwear
Home textiles
Automotive
Mattress
Shoe upper

TECHNICAL INFORMATION:

Diameter [inch]: 30″ – 48″
Machine gauges [E]: 18 – 28
No. of feeders: 48 feeders at 30″
Speed up to [rpm]: 20 rpm at 30″
Speed factor (SF) [feeders per min.]: 600

Product brochure

Contact to sales
