OVJA 0.8 E

A coarse gauge specialist featuring transfer technology for hole patterns and SJ/DJ combinations

Exceptional features and many ways to combine them. This is what makes the OVJA 0.8 E stand out. Since it comes with transfer technology, the OVJA 0.8 E can knit single and double jersey combinations as well as hole patterns and rib transfers.

When we say coarse gauges, we really mean it. The OVJA 0.8 E produces gauges starting at E4 going up to E12. Needles with extraordinarily long latches allow for exceptionally long stitches. In combination, this gives any fabric made on the OVJA 0.8 E a very distinct look. Speaking of combinations: The slider cam can be easily adjusted to any of the three positions possible in 2-way technology. So if you need to change your fabric style quickly – just go for it.

The OVJA 0.8 E knits are definitely worth looking at in outerwear, particularly in sweaters and pullovers. Resemblances to hand-knitted fabrics are fully intended and not accidental. In sturdy shoe uppers, the coarse fabrics made on the OVJA 0.8 E also cut a very good figure.

Technical features:

Type
Double Jersey

Structures
Electronic Jacquard
Transfer

Application
Outerwear
Shoe upper

TECHNICAL INFORMATION:

Diameter [inch]: 30″
Machine gauges [E]: 4 – 12
No. of feeders: 24 at 30″
Speed up to [rpm]: 20 rpm at 30″
Speed factor (SF): 600
