FV 2.0

An expert in top quality for fine rib and rib structures

The FV 2.0 knits fine rib and rib structures with one needle track in the cylinder and one in the rib dial. That makes for the FV 2.0’s versatility: The machine may produce thermal 3F8 (3 x tuck, 5 x knit), double-end knitting, plating, rib tuck, half cardigan, tuck ripple, cross-tubular as well as double face and Milano Rib.

Up to four needles in delayed timing (at E22) guarantee for highest elasticity of any of those fabrics. Setting back yarn guides becomes redundant even when changing stitch length thanks to diagonal stitch cam parts. Those cam parts also effectively prevent plating errors as well as drop stitches and holes.

A 3-hole ceramic yarn guide caters for double thread yarn feeding and the knitting yarn‘s optimal transfer to the needle – again for reliable production of the most different rib structures.
Being such a flexible expert for fine rib and rib structures, the FV 2.0 is a popular choice for fabricating underwear for women, men and children as well as for T-shirts.

Technical features:

Type
Double Jersey

Structures
Body size
Fine rib / bindings

Application
Underwear & nightwear
Outerwear

TECHNICAL INFORMATION:

Diameter [inch]: 13″ – 34″
Machine gauges [E]: 10 – 22
No. of feeders: 66 at 30″
Speed up to [rpm]: 38 rpm at 30″
Speed factor (SF): 1140
